Printing Hints: When you have found your processor start with a printout of of the Processor exploded drawing it makes it easier to overview the partlist structure. The best printout result is in color on an inject printer. Some laser printers may have problems in converting colors to black and white
Item Partno Partdescription Quantity
1 103831 Covering Pl. EG750 CPMZ Cel 1 ST
2 113831 Electronics cables EGxx0 CPMZ 1 ST
Panel ( Picture)
305479 Electronic (Picture)
113835 Cables Sensores etc Partlist
3 193135 Crating EG750 online 1 ST
4 203830 Frame W.Acessories EG750 E 1 ST
5 316830 Tanks+Console w.access.EG750 1 ST
316830.pdf6 316249 Main geartrain tanksupport L 1 ST
316249.pdf Main gear train/tanksupport L7 503830 Drain & Tubes EGxx0 3/4" D+F 1 ST
8 316460 Pump support 2XMD20+MV.EGXX0 1 ST
316460.pdf Pump support 2XMD20+MV.EGXX0
*316450.pdf Pump support 2pumps (spal X-962)9 316698 Blower chann. radial 3x1000W 2 ST
316698.pdf Blower chann. radial 3x1000W10 316487 Dev rack 75cm R2 w guide 1 ST
316487.pdf
11 316498 Wash/Fix rack 75cm R2 w guide 2 ST
316487.pdf
12 316108 Dry rack Rack R38 EG750 ALU 1 ST
316108.pdfSub drawings to Racks
316515 Rackside L w gears R2 +spring
316525 Rackside R w gears R2 +spring
316524 Rackside r.w.gears R2 EG900 (ONLY FIX)
155349 Torque Clutch 79T/10ø Compl.
68325 Torque Clutch 80T/10ø Compl. MISSING
13 Conveyor
129407 Conveyor rack Dolev 4pressXLE
Link to Manual On-line section EG750 f. Dolev 4Press* Older versions
When ordering parts you should always state the s/n and type/part number of the processor. Eg. s/n 01121234 Part no: 317990
